90° Automatic Weld Elbow

90° Automatic Weld Elbow

  • Available in 316L
  • 3-A Sanitary Standard
  • BPE Dimensional Specification
  • Hydro Formed for Precise Shaping
  • ID 32RA Max / OD 32RA Max

90° Automatic Weld Elbows are sanitary grade butt weld elbows with long tangents that are made for use with orbital welding equipment.

SKU:AW2S
Clear

Size Part Number Dimensions
(Tube OD) 316L Wall Thickness A R
1“ AW2A6P-100 0.065 3 1.5
1-1/2″ AW2A6P-150 0.065 3.75 2.25
2“ AW2A6P-200 0.065 4.75 3
2-1/2″ AW2A6P-250 0.065 5.188 3.75
3“ AW2A6P-300 0.065 6.313 4.5
4" AW2A6P-400 0.083 8.313 6
