Stainless Steel Sanitary Tubing
- Bright Annealed Polished Stainless Steel Tubing
- ASTM A270 & 3-A Sanitary Standards
- Maximum 20RA ID (180 grit) / 32RA OD (150 grit)
- Available in 304 and 316L
- Sold In Case Quantity
- Individual Lengths Available – Call or Email For Quote
- Item Does Not Qualify For Free Shipping
- We will Contact Customers to Arrange Freight
Our polished stainless steel sanitary tubing is manufactured in accordance with ASTM A270 and 3-A sanitary standards. All steel tubing is made from cold rolled stainless steel strip with chemical elements specially controlled to enhance weldability. The weld bead is cold-worked to a full finished condition, resulting in a virtually undetectable longitudinal weld. Bright annealing to 1,900°F minimum follows in a controlled atmosphere to preserve maximum structural integrity. The tubes are then mechanically polished to a 180 grit (20 μ-in. Ra maximum) interior and 150 grit (32 μ-in. Ra maximum) exterior finish. Tubes are then line-stenciled with OD, wall, ASTM specifications, grade, and heat number.
You may also like…
| Size | Part Number | Dimensions | Other Specs | ||||
| (Tube OD) | 304 | 316L | Wall Thickness | ID | Gauge | *Lbs./Ft. | *PSI |
| 1/2″ | 78L0865-SAN | 0.065 | 0.37 | 16 | 0.3 | 10833 | |
| 3/4″ | 78L1265-SAN | 0.065 | 0.62 | 16 | 0.475 | 8666 | |
| 1“ | 58L1665-SAN | 78L1665-SAN | 0.065 | 0.87 | 16 | 0.65 | 9750 |
| 1-1/2″ | W58L2465-SAN | W78L2465-SAN | 0.065 | 1.37 | 16 | 0.995 | 6503 |
| 2“ | W58L3265-SAN | W78L3265-SAN | 0.065 | 1.87 | 16 | 1.35 | 4875 |
| 2-1/2″ | W58L4065-SAN | W78L4065-SAN | 0.065 | 2.37 | 16 | 1.7 | 3900 |
| 3“ | W58L4865-SAN | W78L4865-SAN | 0.065 | 2.87 | 16 | 2.035 | 3248 |
| 4" | W58L6465-SAN | 0.065 | 3.87 | 16 | 2.73 | 2187 | |
| 4“ | W58L6483-SAN | W78L6483-SAN | 0.083 | 3.834 | 14 | 3.47 | 2730 |
| 5" | W58L8065-SAN | 0.065 | 4.87 | 16 | 3.77 | ||
| 5" | W78L8083-SAN | 0.083 | 4.834 | 14 | 4.36 | 2184 | |
| 6" | W58L9683-SAN | 0.083 | 5.834 | 14 | 5.245 | 1820 | |
| 6" | W58L96109-SAN | W78L96109-SAN | 0.109 | 5.782 | 12 | 6.858 | 2543 |
| 8" | W58L128109-SAN |
W78L128109-SAN |
0.109 | 7.782 | 12 | 9.27 | 1907 |
| 10" | W58L160109-SAN |
W78L160109-SAN |
0.109 | 9.782 | 12 | 11.62 | 1526 |
| 12" | W58L192109-SAN |
W78L192109-SAN |
0.109 | 11.782 | 12 | 13.97 | 1271 |
Number of Tube Sticks Per Case
| Size | Box Quantity | |
| (Tube OD) | Piece Count | Total Footage |
| 1/2“ | 15 | 300′ |
| 3/4″ | 15 | 300′ |
| 1“ | 15 | 300′ |
| 1-1/2″ | 15 | 300′ |
| 2“ | 15 | 300′ |
| 2-1/2″ | 15 | 300′ |
| 3" | 10 | 200′ |
| 4" | 5 | 100′ |
| 6" | 2 | 40' |
| 8" | 1 | 20' |
